Single slip turnout EKW15

Single slip turnout EKW15 with bedding, manually operated. Standard design with internal switch rails.

Length 230 mm (standard length), crossing angle 15°, branch radius 531 mm.

For diagonal installation two D4 and one D12 spacers are included.

Suitable turnout mechanisms (2 pieces are required): 42620 or 42624.
Please note the operating instructions!

■ Frog and wheel guide completely revised
■ Prototypical passing of the frog possible
■ Groove width in the frog area according to NEM
■ Pre-installed polarisation of the turnout frogs
